Dieci Pegasus 30.16 Parts Catalog – 214 Pages of OEM Factory Specs

If you’ve ever ordered a part for a Dieci Pegasus 30.16 from an aftermarket listing and ended up with the wrong bracket, seal, or hose, you know the frustration. This is the catalog that eliminates that. It’s the official OEM spare parts catalog from Dieci, 214 pages, direct from the factory. No third-party reinterpretation.

The catalog is built around group drawings—each section covers a specific machine system. You get exploded views with numbered callouts and a corresponding parts table listing part numbers, descriptions, quantities, and any notes. Left and right sides are marked DX and SX. Optional accessories are shown but flagged so you don’t order something your machine can’t accept. That kind of clarity saves you from returning parts and waiting another week.

Parts Catalog – Not a Service Manual. Know the Difference.

Don’t be the guy who buys this expecting torque specs or overhaul procedures. This is a spare parts catalogue. It tells you what to order and how the factory labels it. For repair instructions, you need the service manual. But when you need the exact replacement oil seal, hydraulic fitting, or bearing for a Pegasus 30.16, this catalog is your single source of truth. Aftermarket catalogs often group similar parts together or use cross-referenced numbers that don’t match. OEM data means you get the exact Dieci part number.

How the Group System Works on the Pegasus 30.16

Every major system is assigned a group: powertrain, hydraulics, chassis, cab, electrical, etc. Within each group, drawings show assemblies with all components. The drawing number corresponds to a table on the same or facing page. For example, if you’re tracking down a torn hydraulic hose, you’d find the hydraulic group, locate the drawing that includes the hose routing, read the part number from the table, and order it. No flipping through dozens of pages hunting for a vague reference. Dieci designed this for technicians who need to identify parts fast.

What Each Drawing Tells You: Part Numbers, Optional Items, and Symbols

Each drawing includes a symbol legend. Items marked with a slash (/) are not available separately or are supplied only as part of a kit. Items marked with a “#” are in the process of being coded—verify availability with Dieci before ordering. Right and left sides are clearly indicated. If the drawing includes optional accessories (ROPS, auxiliary hydraulics, etc.), those are shown but labeled. That prevents you from ordering a part your machine wasn’t built with. Also, note that the catalog is multilingual: Italian, English, Spanish, French, and German. If you’re working on a machine imported from Europe, the original part names and numbers remain unchanged.

Why You Need the Factory Catalog for Dieci Equipment

Rental yards, construction fleets, and independent mechanics all rely on correct part numbers to minimize downtime. A wrong part means the machine sits idle while you wait for the right one. This catalog eliminates that gamble. It’s the same data the Dieci dealer uses. Combine it with your shop’s inventory system, and you can order ahead. For context on how industrial equipment documentation standards impact repair efficiency, see this Automotive Industry Overview and the related Automotive Industry Overview.

3 Common Mistakes When Ordering Parts (And How This Catalog Fixes Them)

First, assuming a part number from a similar model will fit. It won’t. The Pegasus 30.16 uses specific castings and hoses. This catalog gives you the Dieci part number. Second, ignoring left/right orientation. The DX/SX markings on the drawings prevent you from ordering the wrong-side mirror or step. Third, forgetting about supersessions. Dieci occasionally updates components. The catalog’s issue date reflects the latest known parts. Check with your dealer if the part number seems old. But the drawing will show the correct interface.

For other Dieci machine catalogs, consider the Dieci Zeus 37.7 Parts Catalog – OEM Spare Parts Manual, the Dieci Zeus 35.10 Parts Catalog – OEM 227-Page Parts Breakdown, or the Dieci XRM 732 Parts Catalog – OEM Spare Parts Manual 215 Pages.

FAQ

Is this catalog the same as a service repair manual?

No. This is strictly a parts catalog for ordering replacement components. It does not contain repair procedures or torque specs.

How are parts organized in this catalog?

The catalog is divided into groups based on machine systems—powertrain, hydraulics, chassis, etc. Each group has an exploded drawing with numbered callouts. The table below each drawing lists the part number, description, quantity, and any applicable notes. Left and right sides are marked with DX/SX symbols. Optional accessories are included but marked in the drawings. This structure lets you pinpoint the exact part you need without flipping through hundreds of pages randomly.

Does the catalog cover all variants of the Pegasus 30.16?

It covers the base machine and common options. For serial-number-specific parts, check the index or contact Dieci support.

Can I use this catalog to cross-reference parts for other models?

Not recommended. Each model has unique part numbers. Stick to the Pegasus 30.16 catalog for this machine.

If your goal is to keep that Pegasus 30.16 running without chasing wrong parts, this is the document you need. Download the Factory Manual and stop relying on aftermarket approximations.
