GEHL 8210 Parts Catalog – Factory OEM Mixer Feeder Manual

If you are pulling parts off a GEHL 8210 Mixer Feeder and staring at a pile of bearings wondering which one fits the auger drive, you already know the cost of guessing. I have seen too many jobs stalled because some aftermarket parts diagram had the wrong dimensions. This Parts Catalog from GEHL is 44 pages of factory spec breakdowns — original OEM print, no reprints, no third-party nonsense. It tells you exactly what bolt goes where and what number to order. The first thing you will notice is the abbreviation table on page 2: it decodes every fastener type from Cap Screws to Socket Head Set Screws. That alone saves a trip to the hardware store.

Decal Locations – Why Pages 2–5 Matter

Most guys skip the decal section. Do not. The safety and operation decal locations on pages 2–5 are referenced throughout the catalog. When you order replacement decals, you need the correct part number from this section. The manual also includes the serial number plate location — left side of the main frame at the front left corner. That plate is your key to ordering the right parts. Without it, you are guessing.

Main Drive & Hitch Axles – Critical Subassemblies

Pages 6–7 cover the main drive assembly. Pages 8–9 cover the hitch, axles, and weighbars. I have rebuilt enough mixer feeders to tell you that the hitchjack components (page 26 for later style, page 27 for early style) are often misordered. This catalog gives you the exact part numbers for the hitchjack weldments and hardware. The axle and weighbar section includes the correct bolts and bushings. Use the torque specs on the inside back cover for all fasteners.

Augers and Auger Drives – Where Most Parts Go Wrong

Auger bearings (pages 10–11) and auger drives (pages 12–13) are the most frequently replaced items on these machines. The catalog breaks down each auger assembly with reference numbers for every bearing, sprocket, and shaft. The planetary gearbox is detailed on page 30. I have seen aftermarket manuals combine parts from different models into one drawing. This one does not. Each exploded view is specific to the 8210. If you need the hydraulic motor that drives the auger, it is on page 32 with the correct displacement and mount pattern.

Chaincase and Discharge Components – Assembly Specifics

Pages 14–16 cover the chaincase, chaincase mounting, and cover. The auger drive cover is on page 17. The discharge door and hydraulics (pages 18–19) include the cylinder and hoses. One-piece and two-piece discharge conveyors are separated on pages 20–23. When you rebuild a discharge conveyor, the difference between the one-piece and two-piece design matters for the chain and slat lengths. The catalog makes that distinction clear.

What Does the Components Section Cover?

Pages 26–33 are the components breakdown: hitchjacks, augers, planetary gearbox, hydraulic cylinder (page 31), hydraulic motor (page 32), and universal drive (page 33). Each component gets its own exploded view with a parts list. The numerical index on pages 36–39 lets you cross-reference any part number. I use that index constantly when I find a worn part but don’t know the name — just the number off the casting.

Accessories and Hardware Torque – Don’t Skip the Back Pages

Accessories on pages 34–36 include the safety chain, magnet assembly, 3-point scale stand, battery box, single valve conversion kit, and audible/visual alarms. The standard hardware torque specifications are on the inside back cover. Those torque values are for Grade 5 bolts and Grade B nuts unless specified otherwise. Keep that page open when reassembling — overtightening a flanged lock nut on a chaincase cover will strip the threads fast.

3 Reasons to Choose OEM Documentation Over Aftermarket

First, aftermarket catalogs often re-use drawings from older model years and change the part numbers. This catalog is specific to the 8210. Second, the abbreviations and fastener grades are clearly defined — aftermarket versions assume you know the difference between a FCS and a FHMS. Third, the inside back cover torque table is factory standard. I have seen aftermarket manuals list incorrect torque for 5/8-inch grade 5 bolts. That gets expensive.

If you maintain a fleet of GEHL equipment, check out the related manuals: GEHL SL4640, SL4840, SL5640, SL6640 2005 Parts Catalog, GEHL SL7610, SL7710, SL7810 2005 Parts Catalog – OEM Factory Specs, and GEHL RS6-34 2013 Parts Catalog – Factory OEM Manual. For background on the engines that power these units, see this Wikipedia article on diesel engines or this Wikipedia article on diesel engines.

Frequently Asked Questions

Does this catalog include torque specifications for all fasteners?

Yes. The inside back cover lists standard hardware torque values for Grade 5 bolts, Grade B nuts, and other common fasteners. For bolts marked with a specific grade in the parts list, use those values.

Can I use this parts catalog for a different GEHL model like the 8200 or 8220?

No. This catalog is strictly for the 8210 Mixer Feeder. While some components like standard hardware or decals may cross-reference, the auger assemblies, chaincase, and discharge conveyors are unique to the 8210. Ordering parts for a different model from this catalog will result in incorrect parts. Always verify the model and serial number from the plate on the left front of the main frame.

What if a part number is listed but marked “shown for reference only”?

Items in the parts list without reference numbers are illustrations only — they are not available for purchase as individual parts. You must order the assembly that includes them. For example, a weldment shown in the hitchjack drawing may only be sold as part of the complete hitchjack assembly. Check the numerical index to find the correct assembly part number.

Is this a PDF download or a printed book?

It is a downloadable PDF of the original factory parts catalog, scanned from the GEHL publication. You get all 44 pages exactly as printed. No watermarks, no reprints.

Stop wasting time matching bolts by eyeball. Download the Factory Manual now and get the exact part numbers and assembly diagrams GEHL designed for the 8210 Mixer Feeder.
