GEHL GE 802 Operators Manual

If you’re running a GEHL GE 802 crawler excavator and you’re getting by with a photocopied handbook or some PDF from a forum, stop. I’ve seen guys burn up hydraulic pumps because they didn’t have the right fluid capacity or follow the break-in procedure. This GEHL GE 802 Operators Manual is the factory document – 52 pages of what Gehl wanted you to know before you even fire up the engine. Not a reprint, not a third-party summary. It’s the same paper book that came with the machine from the factory.

General Information – What the Manual Covers

Inside front cover has international symbols – the ones that tell you what that little icon means on the dash before you pull the wrong lever. Then it dives into general information starting on page 1-1. That section covers machine identification, specifications for the engine, hydraulic system, undercarriage, slewing system, dozer blade, standard bucket, and even noise level. If you need the weight of the bucket or the hydraulic relief pressure, it’s in there. Page 1-3 lists all specs in a format that’s easy to cross-reference when you’re ordering parts or checking fluid capacities.

Engine and Hydraulic System Specs – Page 1-3

The engine section on page 1-3 gives you the rated power, displacement, and oil capacity. The hydraulic system spec lists pump flow, system pressure, and recommended fluid. I’ve seen guys put 10W engine oil into a hydraulic system that calls for AW46 – that’s a $2,000 mistake. This manual stops that. It also covers the undercarriage and slewing system – track width, ground pressure, slew speed. All numbers are in Imperial units (pounds, inches, gallons, psi) because that’s what your shop tools read.

Safety and Warranty – Why OEM Documentation Matters

Warranty starts on page 2. Gehl warrants the machine for 12 months from start date. But the warranty is void if you don’t follow the maintenance procedures in this manual. The manual tells you the inspection intervals, the proper warm-up, and the shutdown sequence. It also includes a full section on safety – no guessing what that “hot surface” warning means. You get the factory safety decal locations and what each one says. This is the same info your dealer uses to train new operators. If you’re running a fleet, having this on the wall keeps the foreman honest.

3 Systems Covered: Undercarriage, Dozer Blade, Bucket

The TOC lists three specific systems: “Undercarriage and Slewing System” (page 1-3), “Dozer Blade” (page 1-3), and “Bucket (standard)” (page 1-3). Each one includes dimensional data and operational limits. For example, the dozer blade section tells you the blade width, height, and lift height. The bucket section lists the standard heaped capacity in cubic yards. You won’t find that in a generic manual. This is Gehl’s own data, certified at the factory.

FAQ

Does this manual cover routine maintenance like oil changes?

Yes. It includes the schedule for engine oil, hydraulic fluid, and filter changes as part of the warranty requirements.

What torque specifications are included?

This is an operator’s manual, so you’ll get track tension specs and bolt torque for the bucket teeth – but not engine head bolts. For full service torque values, get the service manual. The operator’s manual gives you the numbers you need for daily operation and basic adjustments.

Why would I pay for this if I can find free manuals online?

Free online copies are often missing pages, have faded scans, or are actually for a different serial number range. This is a clean, original PDF – every page, every symbol, every spec exactly as Gehl printed it. One wrong fluid spec can cost you a pump. That’s worth the price of admission.

Can I use this manual to troubleshoot hydraulic issues?

It will help you identify the system’s normal operating pressures and capacities, but for component-level diagnostics you need the service manual. Use this operator’s manual to confirm you’re not misreading a gauge or putting in the wrong fluid.

Related Manuals

• GEHL RS10-44 2009 Operators Manual – Factory Specs & Procedures
• GEHL RS10-44, RS10-55, RS12-42 2011 Operators Manual – Factory Specs
• GEHL 5635, 6635 1998 Operators Manual | Factory Specs

For transmission specifics on other equipment, check Manual Transmission and Manual Transmission on Wikipedia for general theory. But when it comes to the GEHL GE 802, stick with the factory document.

You need the legit OEM manual to keep your GEHL GE 802 running right – without guessing. Download the Factory Manual now and get the specs Gehl built into that machine.
