GEHL V270, V330 2014 Parts Catalog – Factory OEM Parts Breakdown

If you’ve ever ordered a part for a V270 or V330 and gotten the wrong one because some aftermarket catalog guessed, you know the frustration. This 2014 GEHL V270, V330 2014 Parts Catalog kills the guesswork. 270 pages of exploded diagrams, factory part numbers, and serial number breaks. No reprints, no aftermarket shortcuts.

Every section in this manual came straight from GEHL’s engineering data. SECTION A: MAIN LOADER COMPONENTS covers everything from the chassis and engine to the suspension seats and ROPS/FOPS structure. Need the right part for the hydrostatic drive? It’s in there. Want the seal kit for the lift arm cylinders? The manual lists the exact GEHL part number, not a cross-reference.

Engine and Suspension Coverage in This GEHL Parts Catalog

The ENGINE chapter breaks down both the Yanmar diesel and the mounting hardware. You’ll see the alternator, starter, and even the vibration isolators. For Seats – Standard, Non-Suspension and Suspension, the manual separates standard foam seats from air suspension units. Part numbers for suspension seats are listed with the correct fastener callouts. Check page 1 for the serial number ranges that apply to your machine – V270 SN 023001 and up, V330 SN 133001 and up.

What About the V330 Serial Numbers?

Section A splits controls by serial number breaks. For example, T-Bar Controls with Self-Leveling Valve on V270: SN 023335 and Before, V330: SN 133240 and Before. Then there are separate listings for after those breaks. If you skip the serial number verification, you’ll order the wrong valve spool. The manual forces you to look at the serial number first. Page 2 shows the standard attaching hardware torque values in the inside back cover – use them on every bolt.

7 Key Sections in This Factory Parts Manual

• SECTION A: MAIN LOADER COMPONENT – Chassis, Engine, Hydraulics, Lift Arm, ROPS/FOPS, Seats, Controls
• SECTION B: HYDRAULIC COMPONENTS AND HEATER/HVAC HOUSINGS – Hoses, fittings, HVAC assemblies
• SECTION C: FILTER LISTING, KITS AND ACCESSORIES – Oil, fuel, hydraulic filter numbers and service kits
• SECTION D: SCHEMATICS – Electrical and hydraulic schematics for troubleshooting

Each section uses the same part numbering system the dealer uses. Call in with the number from this catalog and you get the right piece. The Suspension seat parts (air suspension and standard) are listed with their own hardware – bolts, washers, and seat belt options including the three-point restraint.

Use Genuine GEHL Parts – Why It Matters

Genuine GEHL parts are engineered for the load, the vibration, and the duty cycle. Aftermarket copies fail on the torque spec or the thread pitch. The catalog notes lubrication points and nonstandard torque values right in the part description. For the Hydraglide™ Ride Control Assembly, the accumulator and valve part numbers are specific – don’t guess. Order from this manual and save your Saturday.

Related Manuals for Your V270 and V330

Need operating instructions or maintenance intervals? Grab the GEHL V270, V330 Operators Manual – Factory Specs for Skid-Steer Loaders. For a complete parts breakdown of the previous year, check the GEHL V270, V330 2013 Parts Catalog – Factory OEM Parts Breakdown. And if you only run a V270, the GEHL V270 Operators Manual – Factory Specs for Skid-Steer covers the same loaders.

Understanding the diesel engine helps. Read this Wikipedia article on diesel engines for basic principles. The manual covers the entire powertrain. For more technical background, visit this Wikipedia article on diesel engines.

FAQ – Common Questions About This Parts Catalog

Does this manual cover the V330 after serial number 133001?

Yes, it covers V330 GEN:2 models with SN 133001 and up.

Are torque specifications included?

Standard attaching hardware torque values are provided on the inside back cover, referenced on page 2. Nonstandard torques appear in the part description.

What sections are in the manual?

Four main sections: A – Main Loader Components (chassis, engine, hydraulics, suspension seats, ROPS/FOPS, lift arm, controls), B – Hydraulic Components and Heater/HVAC Housings, C – Filter Listing, Kits and Accessories, D – Schematics. Section A alone has over 20 subsections covering every assembly on the machine down to the seat belt options.

Does this manual include schematics for troubleshooting?

Yes, SECTION D contains both electrical and hydraulic schematics. Use them to trace wiring harnesses and hydraulic circuits when diagnosing faults.

This is the same binder the dealership parts counter uses. Stop wasting time with aftermarket parts lists that miss the serial number split. Get the 270-page factory document that matches every bolt and hose to a GEHL part number. Download the Factory Manual now.
