Lingong LG938 Parts Catalog – Factory OEM Parts Breakdown

Every time a part number doesn’t match or you’re staring at a transmission with no idea which bearing is which, you’re burning hours you don’t have. The Lingong LG938 Parts Catalog kills that guesswork. 235 pages of factory exploded views, straight out of Shandong Lingong’s engineering department. No aftermarket translation errors, no missing callouts. You get the exact part numbers and assembly relationships that the assembly line uses. I’ve been wrenching on heavy equipment since before most of you were born – this type of factory documentation is the difference between a job that finishes on time and a parts order that comes back wrong twice.

Engine System Coverage: What’s in Section A

Section A covers the Diesel Engine System. The breakdown starts with the Engine Assembly (part number group A1-2901000918), then moves through the Fuel Tank Assembly (A2-2902000758), the Radiator Assembly (A3-2903000777), the Governor Control System (A4-2901001188), and a separate radiator setup for high-temperature cooling modules (A5-2903000777). Each component has its own exploded diagram with individual part numbers listed in the table. You can trace a hose clamp back to its original bin if you need to. The catalog uses a two-column format – Chinese on the left, English on the right – so international ordering doesn’t require a translator.

Transmission System Section C – Exploded Views and Part Callouts

Section C is the Transmission System. Starts with the overall transmission assembly (C1-2905001043), then the case parts (C2-4110000076) and input parts. If you’re rebuilding a LG938 transmission, you need these diagrams to see how the shaft spacers align and which snap rings go where. The catalog shows the exact assembly order. No guessing which bolt length goes where – the drawing calls it out. For a wheel loader that sees daily abuse, having the right internal parts numbers saves you from pulling the same unit twice because a seal was off by a millimeter.

235 Pages of Verified Part Numbers

Two hundred thirty-five pages. That’s not a slip sheet – it’s a dense reference. Each page has a drawing number and a parts list with quantities, descriptions, and OEM codes. The front matter states this catalog is based on standard product order number E3805215A3908. Non-standard configurations are referenced against that baseline. If you’re ordering parts for a LG938 built after December 2010 (this is the first edition, printed December 2010), double-check your serial number against the catalog’s notes. The manual warns that design changes may occur without notice – that’s standard for production equipment. Always confirm your machine’s production date when ordering.

Who Actually Needs This Parts Catalog?

Home garage guys who bought a surplus LG938 for farm work. Small fleet operators who don’t want to pay dealer markup for every bolt. Independent heavy equipment mechanics who need to price jobs accurately. If you can read an exploded view and turn a wrench, this catalog gives you the same information the dealer’s parts counter has. You don’t need to be a certified tech to match a part number to a drawing. Beginners: take your time. The drawings are clear, but always measure twice before ordering. The catalog lists part numbers, not dimensions – verify with your existing part if you can.

OEM Documentation vs Aftermarket – Why the Difference Matters

I’ve seen aftermarket parts catalogs that list a bolt as “M12x1.5 – 30mm”. The factory catalog gives you the actual Lingong part number, which ties to the correct hardness grade and coating. The aftermarket version might work – or it might shear off under load. This Parts Catalog is an original OEM print from Shandong Lingong Construction Machinery Co., Ltd. It’s the same document their own service centers use. When you download the factory manual, you’re getting the exact part numbering system that the assembly line follows. No translation errors, no generic substitutions.

Does this catalog include engine internal parts?

The engine assembly is shown as a unit in Section A. Internal engine parts like pistons or valves are not detailed; the manual references the engine manufacturer’s separate handbook. For the LG938, the engine parts are in that separate document, not here.

What if my machine has an updated transmission?

If your LG938 has a non-standard transmission variant, the catalog notes you should refer to the standard product drawing and then consult your dealer or Lingong’s website for updates. The base exploded views still apply for most common configurations. For serious discrepancies, contact Lingong directly with your machine’s serial number and production date.

If you’re turning wrenches on a LG938, stop guessing part numbers. Get the factory document that the engineers signed off on. Download the Factory Manual now and keep a copy in your toolbox. Pair it with the Shandong Lingong LG952 2007 Parts Catalog – Factory OEM Parts Breakdown for other Lingong loaders, or the Shandong Lingong LG956L Parts Catalog for larger frames. For a broader view of how construction equipment documentation fits into the industry, read Automotive Industry Overview. And if you need the LG936 version, check the Lingong LG936 2007 Parts Catalog – Factory Exploded Views.
