Dynapac CA144D Parts Catalog

Been there: you tear down a CA144D drum assembly, find a cracked bearing, then spend an hour hunting for a part number because the aftermarket diagram shows a different configuration. That’s lost billable time and a pissed-off customer. The Dynapac CA144D Parts Catalog fixes that. It’s the same 162-page binder the dealer’s parts counter uses – not a photocopied reprint or some third-party compilation. Every exploded view, every reference number, every supersession note comes straight from Dynapac (now part of Dynapac). If you wrench on these rollers for a living, you need this on your bench.

Service Kits and Repair Kits – Factory-Designated Packs

The catalog breaks down the roller into logical groups. Start with Service Kits: 50-hour (part 4700950404), 500-hour (4700950405), and 1000-hour (4700950406). No guessing which filter or belt goes where – the exploded view shows every component in that kit. Then Repair Kits: steering hitch (4700950156), eccentric shaft (4700950153), drum rotation (4700950154), and shock absorber kit for the drum (4812156185). Each kit page lists the individual pieces inside the bag, so you can order a seal kit instead of buying a whole new pump. That’s the difference between a $50 fix and a $500 assembly.

Frame, Drum, and Engine – Exploded Views You Can Trust

Section 3 – Frame – covers frames and scrapers, steering hitch, structure, and noise suppression. Section 4 – Drum – gives you the drum assembly. Section 5 – Engine – is the John Deere 5030HF285 Tier3 plant, with cooling system, combustion air system, fuel system, and exhaust system. Each of those subsystems has its own exploded diagram with callouts keyed to the parts list. You want the water pump gasket? Page 62? No – the manual uses a numerical index at the back. Page 1 of the catalog tells you how to order: machine type, serial number, quantity, part number, denomination, dimensions if applicable. Follow those six steps and the box shows up with the right piece.

Hydraulic System – 7 Subsystems Diagrammed

The hydraulic section alone makes this catalog worth the price. Propulsion system includes the pump (4700378164) with its rotary group (4700950578), valve block (4700950579), and control unit (4700950577). Two different propulsion motors (4700378166 and 4700378143) each have their own rotary group. Vibration system: vibration valve (4700378149) and vibration motor (4700378621). Steering system: pilot valve (4700378153) and steering cylinder (4700378187). Brake system, flow divider option (4700378302) – all listed with part numbers and included items. When a customer says “the roller won’t steer,” you pull up the steering section, identify the pilot valve seals, and order the repair kit. No cross-referencing three different websites.

Electrical Equipment and Driver’s Platform – Don’t Guess the Switch

Section 7 – Electrical equipment – covers the electric system, levelling blade controls, control panel, working lights, ROPS and rotating beacon, driving and direction lights. Section 8 – Driver’s platform – includes platform structure, forward/reverse control handle, ROPS and FOPS, rear view mirror. Those are the parts that break when operators get rough. The catalog shows the whole assembly, so you can order the right toggle switch instead of buying a whole harness.

What Makes This OEM Catalog Different from Aftermarket Copies

I’ve seen so-called “universal” parts books that list a generic hydraulic motor and tell you to “adapt as needed.” That’s a fast track to a comeback. This Dynapac CA144D Parts Catalog is a factory print – the same one used by Dynapac CA144D Parts Catalog – Section: Iii (the notes section that explains remarks, dot-indented items, and spare parts class codes). Class code “A” means three or more units per year – that tells you which parts are high-turnover. Aftermarket docs never include that. The catalog also covers the CC424HF model from serial number 10000320x onward, so if your shop handles multiple Dynapac rollers, you get two machines in one document. That’s a time-saver.

Does This Cover the Vibration System in Full?

Yes. Section 6.2 – Vibration system – lists the vibration valve assembly, the hydraulic motor, and the eccentric shaft kit. The repair kit for the eccentric shaft (4700950153) is cross-referenced to the drum group. If you need the drum rotation kit (4700950154), it’s also in the repair kits section. The catalog does not include service procedures – it’s a parts catalog, not a service manual. For torque specs and disassembly steps, you need the separate service manual. But you can’t order parts without this catalog.

3 Reasons to Stick with the Factory Parts List

First: accuracy. Every part number in this catalog has been verified by Dynapac’s engineering team. Second: completeness. The numerical index at the back lets you look up any part number and find the page, the group, and the exploded view. Third: updates. This edition (SCA144D-US4EN2) replaced the 2010 version – it includes serial number breaks and any supersessions. Third-party PDFs often omit those updates.

FAQ

What machines does this catalog cover?

Dynapac CA144D vibratory roller with serial number starting from 100000101X0D000001, plus it includes the CC424HF from serial 10000320x onward.

Are torque specs included?

No – this is a parts catalog. Torque values are in the service manual.

How many pages?

162 pages. Each page shows exploded diagrams with callouts and a corresponding parts list.

Can I use this to order parts from any dealer?

Yes. The part numbers are the same ones Dynapac dealers use. Provide machine type, serial number, quantity, part number, denomination, and dimensions if needed – instructions are on page 1 of the catalog. That’s all they need.

If you’re pulling wrenches on a Dynapac CA144D Spare Parts Catalogue, you already know the frustration of waiting a week for a part that doesn’t fit. This catalog kills that guesswork. Get the exploded view in front of you, write down the part number, and be done. DYNAPAC CA144D Parts Catalog is the only parts list you should trust. Automotive Industry Overview – that’s the big picture, but for your roller, this catalog is the only picture that matters. Download the Factory Manual now.
