Dynapac CA152AD Parts Catalog – Factory OEM Spare Parts Guide

If you’ve ever had a machine down because you ordered the wrong seal or chased a part number through three different aftermarket websites, you know the pain. This is not a generic scan. The Dynapac CA152AD Parts Catalog is the exact same document the factory hands to dealers. 298 pages of line drawings, reference numbers, and part callouts that match the hardware on your roller. I’ve been turning wrenches for 28 years, and I will tell you straight: without this book, you are throwing darts blindfolded.

Parts Ordering Procedure (Page 4)

Page 4 of the catalog gives you the exact six pieces of information you need to order parts: machine type, roller serial number, quantity, part number, denomination, and dimensions for length orders. Miss any one of these and you are gambling with shipping delays. The manual spells it out in six languages, but the message is the same – give the dealer what they need the first time. This is not a suggestion.

Engine and Roller Serial Number Ranges

Look on page 3 of the manual. You will see the published catalogue issues are tied to specific roller serial numbers. The CA152AD covered here starts from serial number *64521620* and uses the Cummins 4B 4.5T diesel. Knowing that range saves you from ordering parts meant for an earlier revision. I have seen guys put a new fuel pump on a roller that didn’t have the matching block – don’t be that guy.

Why an OEM Parts Catalog Beats Aftermarket

Aftermarket parts books are often cobbled together from old PDFs or third-party scans that miss details. This catalog came straight from Dynapac – the same people who built the machine. The drawings show exactly how each assembly fits, down to the washer and bolt grade. No guesswork. For example, the vibratory system group (see group pages starting after page 5) uses specific thrust washers that generic catalogs often omit. You pay once for the right part, not twice for the wrong one.

3 Critical Details Before You Order

First, always check the roller serial number against the chart on page 3. Second, use the six-point ordering formula from page 4 – don’t assume the dealer will figure it out. Third, note that the manual is for CA152AD rollers built after 2004 with the Cummins 4B 4.5T engine. If your machine is older or has a different powerplant, you need a different catalog. Period.

Using the Catalog in the Field

I keep a copy of this catalog in the shop tablet and a printed binder in the truck. When a vibratory roller comes in with a hydraulic leak, I flip to the vibratory group, find the o-ring part number, and call it in. No disassembly just to read a number – that saves me half a day. The manual’s structure groups parts by system: engine, frame, vibration, steering, brakes. Each group has its own page range, and the notes section on page 5 tracks revisions. You can see exactly when part numbers changed.

Related manuals you might need: Dynapac CA152AD Parts Catalog – OEM Factory Spare Parts Guide for reference, Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec for the cold planer family, and Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer if you run both machines. The construction equipment world shares a lot of the same logic as the Automotive Industry Overview when it comes to parts documentation – OEM is always the baseline.

FAQ – Dynapac CA152AD Parts Catalog

Does this catalog cover the entire CA152AD roller?

Yes, it covers all major systems: engine, frame, vibration, steering, brakes, and electrical. 298 pages with exploded diagrams and part numbers.

Can I use this for older CA152 models?

Check the serial number ranges on page 3. This catalog is for CA152AD starting from serial *64521620*. Older CA152 units likely require a different issue.

What engine is covered in this parts catalog?

Cummins 4B 4.5T diesel. The catalog pages for the engine group list all serviceable components specific to that engine family.

Are part numbers still current or do I need to cross-reference with Dynapac?

Part numbers are factory-issued at the time of printing. Revisions are noted on page 5 under “Changes”. Always verify with your dealer for superseded numbers; some may have been updated.

Bottom line: if you are maintaining a Dynapac CA152AD vibratory roller, this parts catalog is the workbench reference that stops your parts counter from guessing. 298 pages, factory line drawings, and the ordering checklist that keeps the wrong gasket out of your bin. Download the Factory Manual and get back to fixing it right the first time.
