Dynapac CC422V Parts Catalog – OEM Factory Parts Breakdown

If you’ve ever ordered a part by eyeballing a blurry aftermarket diagram and ended up with the wrong bearing or hose, you know the cost in downtime. Dynapac CC422V Parts Catalog stops that cycle. This is the same 201-page document that Dynapac dealers use – not a scanned reprint, not a third-party interpretation. It’s original factory material published in 2006 (issue SCC422V-1EN2) for vibratory tandem rollers with Cummins 4B 3.9 TAA diesel engines.

Roller serial numbers starting from *49120422* are covered. Every part number, every exploded view – it’s all in here. No guesswork.

201 Pages of Exploded-View Parts Diagrams

The manual breaks down every major assembly on the CC422V. Engine, hydraulics, vibration system, steering, frame, drums – each section uses multi-view diagrams with numbered callouts. You get the exact part number and description next to each callout. For example, the rear drum assembly alone shows over 30 components from bearings to scraper blades. No more zooming in on fuzzy photocopies. The scans in this catalog are crisp and readable at full size.

Engine parts (Cummins 4B 3.9 TAA) occupy a dedicated section with its own index. Need a thermostat housing gasket? Page reference is there. The layout is standardized: each group page has a header with the group number and page number, and a footer with the issue status.

Ordering Spare Parts: The Six Required Datapoints

Dynapac spells out exactly what they need to ship you the correct part. Page 4 of the catalog lists six items: machine type, roller serial number, quantity, part number, part denomination, and dimensions if ordering by length. Many shops skip the serial number – that’s how you get a drum seal meant for an earlier build. This catalog lets you cross-reference your serial range against the part revision. If a bushing was superseded, the change is noted in the “Changes” section (Group 3, page 1).

Cummins 4B 3.9 TAA Engine Section – Part Numbers and Diagrams

The diesel engine chapter covers injectors, turbocharger, oil pump, thermostat, alternator, starter, and all gaskets. Each component appears with its Dynapac part number and the equivalent Cummins reference where applicable. For owners doing a rebuild, you can order directly from the catalog and verify fit with your serial number. A common mistake is ordering a pre-2005 cylinder head gasket – this manual shows the updated part for rollers built after serial *49120422*.

Why OEM Factory Documentation Beats Aftermarket Reprints

I’ve seen aftermarket “universal” parts catalogs that lump the CC422V with the CC422 – different engine, different hydraulic pump, different drum width. That wastes time and money. This is the actual Dynapac document, printed in Sweden, issued by the manufacturer. The part numbers match exactly what you’ll get from your dealer. The diagrams show the original design – not a reinterpretation. If you care about getting the right part the first time, don’t trust a third party. Use the OEM source.

Using This Catalog with Your CC422V Serial Number

Find your roller’s serial number plate (typically on the left frame rail near the engine). Cross-reference with the catalog issue: SCC422V-1EN2 covers serial numbers from *49120422* onward. If your roller falls before that, the earlier issue (SCC422V-1EN1) is needed – but this catalog still includes most components that didn’t change across the run. When ordering, always state your serial number to the dealer. Some parts, like the vibration motor flange, were revised mid-production; the catalog shows the revision break point in the “Notes” column.

FAQ

Does this catalog cover the entire CC422V machine?

Yes – all major groups: engine, transmission, vibration, steering, hydraulics, drums, frame, and electrical. 201 pages cover every serviceable part.

Are torque values or service procedures included?

No. This is a parts catalog, not a service manual. It contains exploded views and part numbers only. For torque specs and repair steps, you need the factory service manual. However, having the correct part numbers helps you buy the right gaskets and seals before you start the job – reduces trips to the dealer.

Can I order parts directly from this catalog?

Yes – take the six datapoints listed on page 4 to your Dynapac dealer or any parts supplier that stocks Dynapac. The part numbers are current as of the 2006 issue. Some items may have been superseded; the catalog notes changes in Group 3.

Is this a digital download?

Yes – you get the full 201-page PDF immediately after purchase. Print it or keep it on a tablet in the shop. No waiting for shipping.
