Dynapac CG333HF Parts Catalog – OEM Factory Specs for Vibratory Roller

I’ve seen too many jobs go sideways because somebody ordered the wrong bearing or misread a part number off a worn tag. That’s what happens when you lean on aftermarket parts listings or a photocopy of a photocopy. This Dynapac CG333HF Parts Catalog is the OEM factory document – 250 pages, printed under the Atlas Copco Group. If you’re keeping a CG333HF vibratory roller running, you need this on the bench, not a scanned PDF from some forum.

Ordering Parts the Right Way

Page 4 of this catalog spells out exactly what Dynapac expects when you order spare parts. They want: machine type, roller serial number, quantity, part number, denomination, and dimensions if it’s a length item. Missing any of that and you’re gambling on the delivery. I’ve watched guys order a “hydraulic pump” without the serial number and get the wrong displacement unit. This catalog lists the part numbers and denominations together – you cross-check before you call the dealer. If you need a Dynapac dealer contact, the catalog even has a line for your agent’s info.

Engine and Drivetrain Breakdown

This roller uses a Deutz BF4M 2011 or TD2011 L04W diesel. The parts catalog covers the engine group with OEM part numbers for pistons, injectors, gaskets – the usual suspects. But what I appreciate is the serial number validation. Look at page 3: this edition (SCG333HF-1EN4) is valid from serial *86120333*. If your machine’s serial is earlier, you need the older catalog issue. That kind of specificity keeps you from ordering a water pump that doesn’t fit. For related documentation, check the Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec if you work on the cold planer version.

Vibratory System and Frame Parts

The vibratory roller’s eccentric system takes a beating. This catalog breaks down the whole vibratory group – bearings, shafts, seals – with exploded views and part numbers. I like that the group numbers are cross-referenced in the table on page 5. You get changes notes and service info references so you can track revisions. Don’t trust a third-party parts list that skips the bearing cage update. The Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer follows the same strict group structure.

Why OEM Beats Aftermarket

Aftermarket parts catalogs for construction equipment are a crap shoot. They’ll list a generic bearing that might fit but ignores the factory tolerance class. This OEM document comes straight from Automotive Industry Overview – well, construction equipment manufacturing – and it’s the same binder Dynapac dealerships use. No reprints, no guessed part numbers. Every page is a direct reproduction of the factory spare parts catalogue. If you need the cold planer listing, the Dynapac PL2000LS Parts Catalog – OEM Spare Parts Listings is also available.

250 Pages of Factory Data – What You Get

You’re getting a full 250-page document organized by system groups. The notes section on page 5 tracks changes – critical when Dynapac updates a part. The catalog includes ordering instructions in six languages, so your shop foreman in San Antonio can read the English version while the Swedish office uses the original. For a shop that services multiple contractors, that alone saves phone time.

FAQ – Two Questions From Mechanics Like You

Does this catalog include torque specs for the roller?

This is a parts catalog, not a service manual. It lists part numbers and exploded views. You want torque values? Get the shop manual.

I have a CG333HF with a serial outside the range shown on page 3 – will this still help me?

If your roller serial is lower than *86120333*, this catalog edition (SCG333HF-1EN4) may not cover all parts. Dynapac issued earlier editions for older machines. That said, many common parts like filters and seals carry over. Cross-check your serial with the dealer before ordering anything critical. I’d rather you spend five minutes verifying than waste a week waiting for the wrong part.

If you’re already tearing down a CG333HF and need the factory exploded diagrams and part numbers, this is the only source you should trust. Don’t guess – get the OEM documentation on your tablet or printed. Download the Factory Manual and start ordering the right parts today.
