Dynapac LG500 Parts Catalog – Factory OEM Specs on 70 Pages

You’ve got a Dynapac LG500 Parts Catalog waiting for you on a job site, and that broken vibratory plate isn’t going to fix itself. Every time a junior tech orders a seal by eyeballing it, I see a part that doesn’t match the serial number. This is the factory document that stops that waste. 70 pages of OEM-sourced part numbers, exploded diagrams, and the exact ordering format that keeps your Dynapac LG500 running. It’s the original print from Dynapac – part of the Atlas Copco Group – not some third-party scan with blurred numbers.

Ordering Spare Parts: The 6 Required Fields

Page 4 lists the six pieces of information you must provide to avoid a wrong delivery. Machine type, roller serial number, quantity, part number, part denomination, and dimensions if ordering per length. Miss one field and the order gets kicked back. I’ve seen shops lose a half-day because they didn’t write down the serial number range. That’s time you can’t bill. The catalog spells it out in English, Swedish, German, Italian, Spanish, and French, so if your parts distributor translates, you still get the right info.

Valid Serial Numbers and Engine Identification

This issue (SLG500-3EN1) applies to plates built from a specific serial number – check page 3. Inside, the engine is called out as Hatz 1D81. If your LG500 has that engine, these part numbers match. If someone swapped in a different powerplant, this catalog won’t cover it. That’s why you always verify the serial number before ordering. No guessing.

Parts Catalog Structure: Groups and Changes

Page 5 shows the notes section with a group structure. The catalog groups parts by system (engine, base plate, handle, etc.), each with its own page. Revisions are tracked by issue date – this one is 2010-04. If your plate was built after that date, you’d need a later issue. The parts list uses a dot system to indicate when a part is moved to a different group. You have to read the bottom remarks column to catch those changes. Skip that step and you’ll order a bracket that doesn’t fit.

3 Reasons to Trust Factory OEM Documentation

First, the part numbers come from Dynapac’s own engineering database – not from a parts-supplier guess. Second, the exploded diagrams show how components fit together, so you don’t order a spring that looks right but has the wrong free length. Third, the catalog includes a change history, so you can see if a part supersedes an older number. Aftermarket catalogs strip out that history. That’s why I only trust OEM prints like Dynapac LG500 Parts Catalog – 70 Pages OEM Factory Specs. If you’re working on a cold planer, check Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec or Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer for similar accuracy.

Does This Catalog Cover the Hatz 1D81 Engine?

Yes. Page 3 lists the Hatz 1D81 as the engine for the LG500. The catalog includes every part that connects to or is driven by that engine – mounts, pulleys, fuel system components. If your machine has a different engine, you need a different catalog. The same level of factory-documentation reliability is what keeps heavy equipment in service; engineers in automotive and construction alike depend on this, as noted in this Automotive Industry Overview. For general factory info, visit Dynapac directly.

FAQ

How many pages is the Dynapac LG500 Parts Catalog?

70 pages.

What engine is listed for the LG500 in this catalog?

Hatz 1D81. The engine is identified on page 3 of the catalog.

Can I use this catalog to order parts for a different serial number range?

Only if the serial number of your machine falls within the range listed on page 3. The catalog states “Valid from serial number:” but the specific number is not printed in the excerpt. If your plate was built after the issue date (2010-04) for this edition, part numbers may have changed. You must cross-reference the serial number with Dynapac to confirm this issue applies. Ordering parts from the wrong serial range is the top cause of returns in my shop – three days wasted for a bushing that’s a millimeter off.

Is this the same as the operator’s manual?

No. This is a parts catalog for ordering spare parts. It does not contain operating instructions or maintenance schedules.

Everything on this page is built around one idea: you need the right part number the first time. The Dynapac LG500 Parts Catalog gives you exactly that – 70 pages of factory-sourced data, no compromises. Download the Factory Manual now and stop throwing money at wrong parts.
